How to Enable a Static MAC Address on a Skydio X10 Controller

This resource has been developed for use by Skydio X10 Pilot/Operators and Program Managers. For additional information related to the Skydio X10 Flight System, see Skydio Support or the Skydio X10 Operator Manual.

[note] Prior to initiating this workflow, ensure that the SSID or network name appears in the list of Available Networks under the Controller’s WiFi Settings. [/note]

To verify the SSID or network name in Available Networks:

1. Power on the Skydio 10 Controller
2. Using the menu in the upper left-hand corner of the Home screen, navigate to Information → Device Settings → Networks → WiFi Settings
3. Check Available Networks and verify that the SSID or network name appears in the list of networks. If it does, continue with the workflow below.
4. If it does not, select Add Network, enter the SSID or network name and password, then select Save.
   [note] Enabling the Hidden Network toggle will only hide the SSID in the list of Available Networks on the Controller; information about the devices connecting to the network will still be exposed as devices attempt to connect to the network. Non-hidden networks are considered more secure with the use of a strong password and network encryption. [/note]
5. Your SSID or network name should now appear in the Controller’s list of Available Networks.

To enable a Static MAC Address on the Skydio X10 Controller:

1. Power on the Skydio X10 Controller
2. Using the menu in the upper left-hand corner of the Home screen, navigate to Information → Device Settings → Networks → WiFi Settings
3. From WiFi Settings, select the menu in the upper right-hand corner of the screen to open the menu. Select Advanced Settings.
4. In Advanced Settings, select Manage Networks
5. Under Saved Networks, select the relevant SSID or network name
6. From the SSID screen, select View More and scroll down to locate MAC Address Type. The default MAC Address setting will be Randomized.
7. Select MAC Address Type to open a menu. Select Phone MAC. The Phone MAC refers to the MAC Address of the WiFi Internal Radio embedded in the controller. It is an internal component and does not refer to a separate mobile device or cellular phone.
8. The Phone MAC address will now appear under MAC Address (see image below). This MAC Address can be used to allowlist the Controller under your organization’s SSID or network name.
